Mono PERC Solar Module

OME Good Quality 12.8V 100Ah 200Ah Lithium Battery Pack

Home

Low Voltage

OME Good Quality 12.8V 100Ah 200Ah Lithium Battery Pack

OME Good Quality 12.8V 100Ah 200Ah Lithium Battery Pack

12.8V 100Ah 200Ah Lithium Battery Pack with A grade EVE battery cells. Household use.

  • Payment :

    30% by T/T in advance
  • Shipping Port :

    Shanghai or Ningbo
  • Lead Time :

    10-15 working days after payments

Advantages:

Higher Safe Performance and Longer Cycle Life

With breaker and fuse

High Scalability

Up to 15pcs to connect in parallel

Wide Compatibility

Compatible with most of the leading inverter brands

Advanced Battery Management System

Smart BMS from famous brands, to monitor the battery's temperature, current, prevent over-current

and etc. Take good control of the charging and discharging of battery to max.the lifespan

Environmentally Friendly

From reduced carbon emissions to increased energy savings, we've got you covered. It will help reduce

your carbon footprint by storing energy from renewable sources like solar power and wind power




Model PNG-E12100-LV PNG-E12200-LV
Nominal Voltage 12.8V
Nominal Capacity 100Ah 200Ah
Nominal Energy 1.28kWh 2.56kWh
Output Voltage Range 10.8-14.6V
Charge Voltage Range 12.8-14.6V
Discharge Cut-off Voltage 10.8V
Max.Charge/ Discharge Current 1C, 100A 1C,200A
Recommend Charge Current(Continuous) 0.5C,50A 0.5C,100A
Scalability Up to 15pcs connected in parallel
Depth of Discharge (DOD) 80%/25℃/0.5C,SOC≥80%
Display Type LCD Screen (Optional)
Protection Level IP65
Working Temperature Range Charge:0℃~+55℃.Discharge:-20℃~+55℃
Storage Temperature Range -10℃~+30℃
Humidity 5%~95% RH
Cycle Life ≥4000cycles
Protection Built-in smart BMS,Breaker,Fuse
Communication Port CAN/RS485
Warranty 3years
Installation Floor-Mounted
Cooling Mode Air-cooling
Dimension(L*W*H) 255*165*215mm 480*165*240mm
Weight 16kgs 28kgs





FAQ:

1: Can the product be shipped to my area?
We export to most countries/regions (Centre/ South America, EMEA, SEA, SSA, AU). We will check and confirm for you after you provide the region.

2: How can I make payment?
100% T/T or maximum we can accept 30% T/T in advance and 70% T/T upon goods ready before shipment.
